Introducing the Cartographer Probe v3: The Ultimate Eddy Current Displacement Sensor for 3D Printers

DOCUMENTATION CAN BE FOUND HERE

THIS PROBE WORKS WITH BOTH USB and CAN SETUPS.

THIS IS FOR THE UNASSEMBLED, FLAT PACK EDITION.

What is new?

This latest version allows you to switch between using either CAN or USB via firmware, no need to re-solder anything.

Cartographer and CAN

CAN provides easy and simple wiring, no need to run multiple wires from your MCU or use one of your limited number of USB ports. Just tap into your Toolhead's CAN output and enjoy a seamless setup.

It is recommended to run your CAN network at a baud rate of 1,000,000.

Our CAN Probe is recommended for use on BigTreeTech CAN Boards. It does and will work on Fly/Mellow & Fysetc Toolboards, but only BigTreeTech provides a CAN output, making wiring significantly easier.

Input Shaping (adxl345)

With the probe's proximity to your printer's nozzle, the adxl345 provides a higher level of accuracy when running input shaper than motor-mounted alternatives.

Overview

Say hello to the future of 3D printing—The Cartographer Probe. Designed for the discerning 3D printing enthusiast and professional alike, our Eddy Current displacement sensor elevates your printing experience by delivering unparalleled accuracy when scanning your 3D printer’s bed surface. Achieve print perfection every time!

Features:

• Advanced Eddy Current Technology: Benefit from cutting-edge Eddy Current technology to get extremely precise measurements of your 3D printer bed’s surface.
• High-Speed Scanning: No more waiting. Cartographer scans your print bed faster than traditional methods, letting you get back to what you love—printing.
• Universal Compatibility: Designed to be compatible with a wide range of 3D printers, from consumer to industrial models.
• Easy Installation: With our step-by-step guide, installation is a breeze—even if you’re not a tech whiz.
• Compact Design: With its sleek, unobtrusive design, the Cartographer probe easily fits into any 3D printing setup.
• Durable Materials: Crafted from high-quality components to ensure longevity and consistent performance.

Specs:

What is included?

• 1 x Cartographer Probe with CAN and Input Shaping
• 1 x 1.8m USB Cable (USB-A to JST-PH)
• 1 x 18cm CAN Cable (DuPont to JST-PH)
• 1 x Silicone Nozzle Brush
• 1 x Cartographer Fastener Pack

Benefits:

• Optimize Print Quality: Accurate bed leveling leads to higher quality prints—say goodbye to imperfections and defects.
• Save Time: Faster scans and fewer print retries mean you complete your projects in record time.
• Resource Efficiency: Accurate first-time prints mean less waste of filament and other materials.
• Peace of Mind: Knowing your printer’s bed is perfectly leveled allows you to focus on your creative journey, not on troubleshooting.

Take Your 3D Printing to the Next Level with Cartographer!

No more guesswork, no more wasted time, and most importantly, no more compromise on quality. Get your Cartographer Probe today and step into a world of 3D printing like you’ve never experienced before.
